Supply Unit For Water Pumps

Supply Unit For Water Pumps

Product Details:

X

Product Description

Supply Unit For Water Pumps

Specification: Supply Unit For Water Pumps

  • Function of a Kaplan turbine
  • Closed water circuit with submersible pump, throttle valve and tank
  • Adjustment of flow rate with throttle valve
  • Loading the turbine by use of air-cooled eddy current brake
  • Rotor with fixed blades
  • Adjustable guide vanes for setting different angles of attack
  • Non-contact speed measurement at the turbine shaft and force sensor at the brake for measuring the torque
  • Digital display for pressures, temperature, flow rate, speed and torque

Technical Data

Kaplan turbine

  • Max. output: 1000W
  • Max. speed: 3700min-1

Distributor

  • 8 guide vanes, adjustable: -15°...45°
  • External diameter: 120mm, internal diameter: 60mm
  • Rotor, 4 blades, fixed
  • External diameter: 120mm, internal diameter:
  • 60mm, pitch: 80mm

Submersible pump with motor

  • Max. flow rate: 250m³/h
  • Max. pump head: 11m
  • Nominal power: 3,1kW
  • Tank: approx. 350L
