Universal Tool and Cutter Grinding Machine

Product Description

Description: Functional Versatility: The instrument basically designed for sharpening and recondition wide range of high speed and carbide tipped tolls as side & face milling cutters, cylindrical cutters, angle cutters, convex & concave cutters, gear hobs, end mills, shell mills reamers, drills, taps etc. Technical Specification: Max. swing on std. center mm 250 250 280 Swing with raising blocks mm 350 350 380 Length between work head and RH tail stock mm 330 520 610 Admit between centers mm 440 670 760 Max. Height center of wheel above table mm 300 300 380 Longitudinal traverse mm 400 480 510 Cross traverse mm 200 250 250 Swivel either side of centre(End scale) deg. - 9 9 Size of table mm 750 x 115 920 x 140 1010 x 140 Vertical adjustment of wheel head mm 210 210 290 Wheel Head Swivel deg. 3600 3600 3600 Tilting in either direction deg. 180 180 180 Spindle speed rpm 3800/5600 3800/5600 3800/5600 Motor power KW/HP 0.75/1 0.75/1 0.75/1 Net weight of the machine kg. 750 1150 1250 Gross weight of the machine kg. 900 1350 1450 Dimension of Machine (L x W x H) mm 1075 x 1100 x 1400 1325 x 1170 x 1460 1325 x 1170 x 1460
