All Geared Universal Milling Machine

All Geared Universal Milling Machine

50000.00 - 500000.00 INR/Pack

Product Details:

X

All Geared Universal Milling Machine Price And Quantity

  • 50000.00 - 500000.00 INR/Pack
  • 1 Pack

All Geared Universal Milling Machine Trade Information

  • 10 Pack Per Month
  • 10-30 Days

Product Description

Description:

All Geared Universal Milling Machine is used to precisely shape metal and other solid materials. We offer manually operated, mechanically automated and digitally automated CNC milling tools. Our heavy duty, versatile tools are built for hassle-free operations. It is suitable for accurate and diverse jobs. They are tough, stable and dependable. Their user friendly features and higher cutting capacity leads to higher efficiency. These devices are made using high quality components to meet extreme load conditions. They are simple to maintain and have longer working life. Our tools are applicable in machine shops and tool rooms of many industries. This device comes in 4 different specifications or formats as shown in the below table. There are milling tools with smaller as well as larger work surfaces and therefore can be selected depending on the most specific requirements. Our universal tool supports longitudinal, vertical as well as cross feeds. It has been designed for faster work and comes with a rotating spindle which can rotate at the speed of 40 to 1200 RPM ensuring really quick and efficient work in the industries. Fabricated from high quality raw materials, this is a long lasting instrument which ensures to give a comparatively greater and hassle-free functional life than other ordinary machineries available in the market. The instrument is designed for optimum performance and is just the right device for robust and bulk industrial applications.

Features:

  • High Quality Close grained Cast Iron All Slides Grinded on Slide way Grinder and closely scraped.
  • Steel Sliding gears carried on Splined shafts, Spindle and Arbor made of alloy steel hardened and ground.

Technical Specifications:

Model

DIGR043

DIGR043/1

DIGR043/2

DIGR043/3

DIGR043/4

TABLE

Working Surface

1300 x 300

1400 x 330

1600 x 350

1800 x 400

2000 x 450

T. Slot Nos./ Size

3.16

3.22 T NUT

3.22 T NUT

3.22 T NUT

3.22 T NUT

T. Slot Centre

70

80

85

90

95

Swivel

+ 45 deg

+ 45 deg

+ 45 deg

+ 45 deg

+ 45 deg

Longitudinal Travel-X

700

800

1000

1200

1300

Cross Travel-Y

215

260

340

380

450

Vertical Travel-Z

450

510

600

650

700

FEEDS

No. of Feeds

18

18

18

18

18

Long. Feed/Min

23-420

23-420

23-420

23-420

23-420

Cross Feed/Min

23-420

23-420

23-420

23-420

23-420

Vert. Feed/Min

3-70

3-70

3-70

3-70

3-70

No. of Rapid Feed

1

1

1

1

1

Rapid long & Cross / Min

1050

1050

1050

1050

1050

Rapid Vertical Min

175

175

175

175

175

SPINDLE

No. of Spindle Speeds.

12

12

12

12

12

Range of Spindle Speeds

40 to 1200 RPM

40 to 1200 RPM

40 to 1200 RPM

40 to 1200 RPM

40 to 1200 RPM

Spindle Taper

ISO 40

ISO 40

ISO 40

ISO 50

ISO 50

Arbor Diameter

25.4

25.4

32

40

40

POWER

Main Motor (H.P)

3

5

7.5

10

10

Feed Motor (H.P)

2

2

3

3

5

Coolant Motor (H.P)

0.1

0.1

0.1

0.1

0.1
