Turbine Fuel System Trainer

Turbine Fuel System Trainer

Product Details:

20000 INR/Unit
X

Price And Quantity

  • 20000 INR/Unit
  • 1 Unit

Trade Information

  • 10-30 Days
  • Export Worthy
  • ISO

Product Description

Description:

Turbine Fuel System Trainer is specially designed to allow trainees to understand the fundamentals of turbine fuel system components and how they are inter connected in a typical aircraft fuel system. The system is mounted on a mobile stand. This completely functional Turbine Fuel System Trainer includes a capacitance fuel system, with multiple probes set at different angles to demonstrate non-linear fuel quantity indications. Capacitance fuel quantity fuel system comes with awing tank and all associated plumbing. This functional fuel system is designed to represent a complete turbine engine fuel system. It includes a fuel management panel, fuel transfer system and capacitance fuel quantity in dicating system. An instructors panel is included allowing faults to be added to assistin teaching troubleshooting. The fuel system panel includes fuel quantity indicators, a fuel transfer selector valve, fuel transfer and low fuel warning lights, fuel pressure and flow indicators, and complete fuel system drawings.

Features:

  • Fully functional and configured like a typical turbine engine aircraft fuel system.
  • Instructors panel for introduction of usual system faults and errors Aircraft hydraulic cylinder sequenced by a sequencing valve
  • Training manuals including troubleshooting charts, explanatory text, symbols charts,wiring diagrams, flow schematics, and component cut-away diagrams.
  • Includes over head transparencies and laminated fuel system drawings.
  • Works with 28 volt DC power or with an APU
  • Designed with aircraft parts

Components:

  • The trainer is designed using actual aircraft parts, including:
  • Fuel quantity indicator
  • Fuel quantity sender / transmitter
  • Fuel flow/pressure gauge
  • Electric fuel transfer/boast pump
  • Fuel transfer selector valve
  • Fuel filter
  • Fuel lines both flexible and metal lines
  • Circuit breakers switches and electrical components
