Torsion of Bars

Specification of Torsion of Bars

  • Elastic torsion of bars
  • 2 movable bearing blocks with clamping chuck for mounting of bars, 1 fixed and 1 movable bearing
  • 2 movable angle indicators clampable to the bar
  • 4 bars: round bar with full cross-section, tube, longitudinally slotted tube, square tube
  • Application of load to the bar by a mass disc, a deflection roller and loads
  • Storage system to house the components
  • Experimental setup in frame

Technical Data

  • 4 brass bars, l=695mm
  • Round bar, d=6mm
  • Tube, slotted tube
  • D=6mm, wall thickness: 1mm, slot width: 0,3mm

Square tube

  • Wxh: 6mm, wall thickness: 1mm
  • Disc to apply the load
  • Effective radius: 110mm
  • Angle indicator
  • Measuring range: -90°...+90°, graduations: 1°

Load

  • 1x 1N (hanger)
  • 4x 1N
