Crank And Connecting Rod Apparatus

Crank And Connecting Rod Apparatus

50000.00 - 500000.00 INR/Pack

Product Details:


Price And Quantity

  • 50000.00 - 500000.00 INR/Pack
  • 1 Pack

Trade Information

  • 10 Pack Per Month
  • 10-30 Days

Product Description

Crank And Connecting Rod Apparatus

Technical description of Crank And Connecting Rod Apparatus

  • This experimental unit demonstrates the conversion of smooth rotary motion into reciprocating motion.
  • The input angle is set on a ball bearing mounted crank disc made of anodised aluminium and read off on an angle measuring scale integrated into the base plate. A millimetre scale is fitted for the outlet stroke. The crank radius can be adjusted in three positions.
  • The simple insertion of a bolt enables the swivelling cylinder to be locked, thus a crank drive with either a fixed or oscillating cylinder can be demonstrated.
  • The components are attached to a solid, painted base plate. Two handles make the unit easier to carry.

 Specification of Crank And Connecting Rod Apparatus

  • Experimental units on crank drives, with either fixed or swivelling cylinder
  • Ball bearing mounted crank disc, anodised aluminium, 3 different crank radii
  • Connecting rod black anodised aluminium
  • Painted base plate with handles

 Technical data of Crank And Connecting Rod Apparatus

  • Crank radius
  • 25mm
  • 37,5mm
  • 50mm
  • Connecting rod length: 150mm
