Hooke's Coupling Apparatus

Technical description of Hooke's Coupling Apparatus

The table model demonstrates the transmission of angular motion to joint shafts, the related gimbal error and how this error can be rectified using hooke's couplings. The model consists of two hooke's couplings that are connected by a split intermediate shaft. The deflection angle of both joints can be set individually and read on the scales. Drive is achieved by turning a hand wheel. On the drive and power take-off sides there are further angle measuring scales made of transparent plastic with which the difference between the angles of the shafts can be determined.

Specification of of Hooke's Coupling Apparatus

  • Benchtop experiment on gimbal error and its avoidance on articulated joints
  • Hooke's coupling, standard industrial parts
  • Scales made of transparent plastic
  • Ball bearing mounted shaft ends
  • Solid, painted base plate
  • Lxwxh 360x280x185mm

 Technical data of Hooke's Coupling Apparatus

  • Shaft diameter: d=16mm
  • Scale disc diameter: d=100mm

 Dimensions and weight of Hooke's Coupling Apparatus

  • L x w x h : 360 x 280 x 185 mm
  • Weight : approx. 7 kg
