Heat Conduction in Solids

Technical Description of Heat Conduction in Solids

The fundamental laws of steady-state thermal conduction in solid bodies can be investigated with this experimental unit. The specimens are arranged between an electrical heater and a water-cooled plate. A Dewar vessel prevents the exchange of heat with the surrounding environment. The specimens are equipped with several temperature measuring points. The heat transfer rate is determined via the current and voltage of the heater.

Specification of Heat Conduction in Solids

• Linear conduction in metals
• Specimens placed between electric heater and water-cooled plate
• 6 Specimens (2x copper, aluminium, steel and 2x stainless steel)
• Heating capacity, adjustable
• Raised tank for constant water pressure
• 2 Thermometers for water temperature
• 4 Temperature sensors, display with selector switch
• Voltmeter, ammeter

Technical Data of Heat Conduction in Solids

• Heater: 365W

Specimens

• Copper, Dxl: 40x65mm and 40x30mm
• Aluminium, Dxl: 40x65mm
• Steel: Dxl: 40x30mm
• Stainless steel: Dxl: 40x65mm and 40x30mm
• Dewar vessel: 2.1L
• Raised tank: water pressure: 356mmWC

Measuring ranges

• Temperature (thermometer): 2x -10...50°C
• Temperature (sensor): 4x 0...200°C
• Voltage: 0...230VDC
• Current: 0...1.5A

 Dimensions and Weight of Heat Conduction in Solids

• l x w x h: 550 x 350 x 780 mm
• Weight: approx. 43 kg
