Electro Hydraulic Servo Shear Testing Machine

Electro Hydraulic Servo Shear Testing Machine

Product Details:

X

Product Description

Electro-Hydraulic Servo Shear Testing Machine, Elastomeric Bearing Test Machines

  • The hydraulic system features a quick withdraw unit to promote efficiency.
  • Electromechanically adjustable test space between upper and lower compression platen. Horizontal shear components are moveable electromechanically and easy to operate.
  • Multi-channel coordinative digital load control system makes it more convenient to perform tests.
  • A wide range of test projects are supported by the testing software (14 categories), perfect support for the latest mechanics performance testing standards on rubber bearing products.
  • Support for management permissions for various user types (Operator, administrator and engineer).
  • Easy to set testing methods. Administrators may configure in a specific range of settings under related standards, pre-installed with two sets of testing schemas (standard testing schema and custom testing schema).
  • Highly automatic testing process. Capable of general functionalities including automatically aligning with zero, smooth continuous loading and un-loading, automatic sustaining. Capable of monitoring the whole testing process, automatic testing data measuring and processing, automatic testing curve displaying, automatic saving the source data and curves of tests.

Technical Specifications:



Capacity

20000kN

25000kN

Load measurement range

0.4%~100%

Load measurement accuracy

±1%

Load resolution

±1/500000 of Max capacity, no stepping, no change in full scale

Piston displacement measurement accuracy

±0.5%

Piston speed adjustment range



0.1~40mm/min

Piston travel of vertical cylinder

300mm

Horizontal shear capacity

3000kN

Horizontal piston travel

300mm

Rotation lifting capacity

2000kN

Upper/lower compression platen distance

1800mm(or customized)

Compression platen dimensions

1200mm×1200mm

Axial deformation measurement range

0~50mm

Lateral deformation measurement range

0~15mm

Horizontal shear deformation measurement range

0~300mm

Frame dimensions

6000×2500×6600mm3

Hydraulic system dimensions

1500×1550×1400mm3

Power supply

41kW/AC380V/50Hz
