Automatic Electro Hydraulic Shear Testing Machine

Automatic Electro Hydraulic Shear Testing Machine

Product Details:

X

Product Description

Automatic Electro-Hydraulic Shear Testing Machine for Elastomeric Rubber Bearing

This product is integrated with a multi-channel coordinative digital load control system, enabling controlling methods including constant deformation speed, constant loading speed and etc., meanwhile switches smoothly in between. The system retrieves testing data automatically, and then processes the data under regulations and standards. It takes no human resources to read deformation data, requiring only one operator to perform the whole test. Assistance is required to install specimen or perform rotation tests. The measuring and controlling unit is developed by our own engineers, integrated with the leading high-performance Controller, which is usually equipped on high-end material testing machines, and the pioneered modular Test Live computer testing software ensuring the reliability and precision of the system. After years of application and refinement, our system features matured technologies, reliable operations and powerful functionalities. The test data of load, displacement and deformation are automatically retrieved, processed and stored meanwhile displaying real-time testing curves. Test reports can be printed under related standards.

This product adopts a four-column structure as its main frame, featuring a stable, high-stiffness structure, as well as long-term stability, convenient operations, reliability and safety.

Technical Specifications:



Capacity

20000kN

25000kN

Load measurement range

0.4%~100%

Load measurement accuracy

±1%

Load resolution

±1/500000 of Max capacity, no stepping, no change in full scale

Piston displacement measurement accuracy

±0.5%

Piston speed adjustment range



0.1~40mm/min

Piston travel of vertical cylinder

300mm

Horizontal shear capacity

3000kN

Horizontal piston travel

300mm

Rotation lifting capacity

2000kN

Upper/lower compression platen distance

1800mm(or customized)

Compression platen dimensions

1200mm×1200mm

Axial deformation measurement range

0~50mm

Lateral deformation measurement range

0~15mm

Horizontal shear deformation measurement range

0~300mm

Frame dimensions

6000×2500×6600mm3

Hydraulic system dimensions

1500×1550×1400mm3

Power supply

41kW/AC380V/50Hz
