Determination Of The Settling Velocity

Specification of Determination Of The Settling Velocity

  • Experimental unit to determine the settling velocity of different spheres
  • 2 transparent cylinders
  • Marking of the measuring section
  • Cover with guide tube to insert the sphere
  • Sluice to remove the spheres from the cylinder
  • 10 spheres of various densities and diameters
  • 2 areometers to determine the density of the fluids
  • Stopwatch to measure the sedimentation time

Technical Data

2 cylinders

  • Inner diameter: 92mm each
  • Height: 1330mm each
  • Sink height: 1000mm each

Spheres

  • Aluminium (density: 2,7kg/dm³)
  • 2x 5mm diameter
  • 2x 10mm diameter
  • Polyoxymethylene (POM), density: 1,41kg/dm³
  • 2x 5mm diameter
  • 2x 10mm diameter
  • Polyamide (PA), density: 1,13kg/dm³
  • 2x 10mm diameter
