Product Description

Laminar Flow Table

A floor standing unit developed to simulate perfect flow, demonstrate Hele-Shaw principles & accept student made models.

Working section support and end tanks moulded from glass reinforced plastic (GRP).
Working section made from laminated glass (dimensions of top glass 606mm x 892mm).
Lower glass plate incorporates 8 pre-con-nected sinks/sources in cruciform pattern and viewing graticule.
A system of pipes, valves and manifolds enables any configuration of sinks and sources to be used.
Includes dye injection system and adjust-able knife edge weir for rapid, accurate adjustments of table flow.
Includes 3gm blue dye powder to make one litre dye solution and comprehensive in-struction manual with illustration.

Technical Detail:

Item	Laminar Flow Table
Width inside moulding	610mm
Length of glass plates	892mm
Distance between glass plates	3.2mm
Sinks/sources	8 tappings in 7 positions
Dye injectors	19 hypodermic needle

Models supplied:

2x canal banks
2x rectangles
3x cylinders
1x aerofoil 3 gm of blue dye powder also supplied. (Makes 1 litre of dye solution when added to water)

DIDAC INTERNATIONAL
