Deformation Of Straight Beams

Specification of Deformation Of Straight Beams

  • Elastic lines of statically determinate and indeterminate beams under various clamping conditions
  • 3 steel beams with different cross-sections
  • 1 brass and 1 aluminium beam
  • 3 articulated, height-adjustable supports with force gauge
  • 1 support with clamp fixing
  • Force gauges can be zeroed
  • 3 dial gauges to record deformations
  • Loads with adjustable hooks
  • Anodised aluminium section frame housing the experiment
  • Storage system to house the components

Technical Data


  • Length: 1000mm
  • Cross-sections
  • 3x20mm (steel)
  • 4x20mm (steel)
  • 6x20mm (steel, brass, aluminium)
  • Frame opening: 1320x480mm

Measuring ranges

  • Force: -50..+50n, graduations: 1n
  • Travel: 0...20mm, graduations: 0,01mm


  • 4x 2,5N (hanger)
  • 4x 2,5N
  • 16x 5N
