Controlled System Module Temperature

Controlled System Module Temperature

50000.00 - 500000.00 INR/Pack

Product Details:


Price And Quantity

  • 50000.00 - 500000.00 INR/Pack
  • 1 , , Pack

Trade Information

  • 10 , , Pack Per Month
  • 10-30 Days

Product Description

Controlled System Module: Temperature

Specification: Controlled System Module Temperature

  • Construction of a temperature control loop
  • Ready-to-install compact panel assembly
  • Electric heater with thermostat and dry-running protection
  • Direct temperature display at heater outlet with bimetallic thermometer
  • Heater is either an actuator or a continuous heater
  • Plate heat exchanger, operating in counter-flow or parallel-current mode
  • Primary circuit with heater and heat exchanger, connected to water supply of base module
  • Flow of primary circuit controlled by hand-operated valve
  • Secondary circuit of heat exchanger connected to laboratory water supply

Technical Data

Plate heat exchanger

  • Number of plates: 20
  • Heat transfer surface: 0,72m²
  • Flow rate: max. 3m³/h

Heater with thermostat and dry-running protection

  • Power output: 2kW
  • Temperature limitation by thermostat: 65°C
