Dissolved Air Flotation

Dissolved Air Flotation

Product Details:

X

Product Description

Dissolved Air Flotation

Specification Of Dissolved Air Flotation

  • Removal of solids from raw water using dissolved air flotation
  • Conditioning of the raw water by flocculation
  • 3 Metering pumps for chemicals
  • Flocculation tank with 3 chambers and 4 stirring machines
  • Flotation tank with electrically driven scraper
  • Pressure tank and 2 circulation pumps
  • Relief valve
  • Separate supply unit with tank and pump for raw water
  • Electromagnetic flow rate sensor
  • Measurement of flow rate, pressure and pH value
  • Control of the pH value

Technical Data

Tanks

  • Flotation tank: 150L
  • Flocculation tank: 45L
  • Raw water: 300L
  • Treated water: 80L
  • Sludge (float): 15L

Raw water pump

  • Max. flow rate: 135L/min
  • Max. head: 7,0m

Circulation pumps

  • Max. flow rate: each 18L/min
  • Max. head: each 50m

Metering pumps

  • Max. flow rate: each 2,1L/h

Stirring machines

  • Max speed: each 600min-1
