Central Electrics Lighting Board

Central Electrics Lighting Board

Product Details:

X

Product Description

Description:

This training stand is especially developedfor practical use in the appropriate learning fields. In addition to the wiringaccording to the circuit diagram, the diagnosis and programming using workshoptester via OBD is also possible. The necessary connections betweenthe control unit and the components must be made according to the wiringdiagram by the trainees themselves. For better identification of the CANconnections between the control units, laboratory cables are supplied with 4 mmsafety sockets in different color coding. The inputs and outputs of theinstalled components are displayed in digital printing on the front panels. Aspecial film allows you to write on the panel with water-soluble pens. Thisensures high practicality.



Components:

  1. Control unit
  2. Steering control unit with switch unit
  3. Diagnostic Interface
  4. Headlight range control adjustment manually
  5. Steering control unit with switch unit
  6. Light switch
  7. Wiper Motor
  8. H7 Headlights
  9. Fog lamps with associated control unit
  10. Static Cornering Light
  11. Rear lights including fog light and reversinglights
  12. Brake Light
  13. Brake Light Switch
  14. Hazard warning switch and interior light withdoor contact switch
  15. Complete Trailer Lighting on the back side



Equipment:

  1. Immediately use able and wheeled functionalmodel
  2. Lockable Failure Box on the back side
  3. Regulated power supply
  4. All necessary connecting cables
  5. On the front panel marker pens can be used
  6. OBD diagnostic interface

Learning objectives:

  1. Naming of electrical and electroniccomponents, assemblies and systems
  2. Testing and maintenance of electrical andelectronic circuits
  3. Selecting and using electrical test andmeasurement equipment
  4. Measuring and assessing electrical parametersand signals



Specifications:

  1. Power supply: 110/240 Volt
  2. Dimensions: L x W x H 1600 x 800 x 1950 mm
  3. Weight: about 140 kg
