Brake control unit

Brake control unit

Product Details:


Product Description

Brake control unit

Control unit for the powder brake. It allows measuring the rotating speed and the torque generated by an electrical motor. It also provides the excitation voltage to the brake. The speed and the torque are displayed by means of instruments; analogue outputs are also available.

  • Speed section: 40 division instrument, class 1.5
  • Ranges: 2000 - 4000 - 6000 rpm, with switch
  • Torque section: 50 division instrument, class 1.5
  • Ranges: 10 - 20 Nm, with switch
  • Power supply section for the brake:
  • Output: from 0 to 20 Vdc, 1 A
  • Supply voltage: 230 V, 50/60 Hz


* Tips on getting accurate quotes. Please include product name, order quantity, usage, special requests if any in your inquiry.
