Tensile Stress Relaxation Testing Machine

Tensile Stress Relaxation Testing Machine
Tensile Stress Relaxation Testing Machine
Send Inquiry
Product Code : DISR006
Brand Name : DIDAC
Product Description

Tensile Stress Relaxation Testing Machine, Computerized Material Testing Machines

Features of Tensile Stress Relaxation Testing Machine, Computerized Material Testing Machines



  1. Dynamic display of load, displacement, deformation and real-time testing curve on the screen.
  2. Support saving, instant retrieving and inspection of testing results.
  3. Capable of re-analyzing test data and curves, and partial zooming of testing curves at will.
  4. Open testing report, support custom testing template, automatic generation of testing report, which can be printed, previewed or saved as files.
  5. Support Excel report templates and customized editing of test reports.
  6. Integrated with travel limit protection and full scale overload protection.
  7. Features a large test space that satisfies both GB requirements (longer than 60 times the specimen’s diameter), as well as American and European requirements (not less than 2.4 meters).
  8. Real-time drawing of curves of remaining load with time, or temperature with time.
  9. Algorithm to predict specimen’s stress relaxation performance after 1000 hours (or any specified value in hours), with the option of single or double logarithm. Capable of predicting with standard specimen data or real-time collected data (Suggested). Integrated with an extensive specimen library to improve the precision and reliability of testing results.



Technical Specifications

Capacity

300kN

Load measurement range

6~300kN

Load measurement accuracy

±0.5%

Load resolution

±1/500000 of Max capacity, no stepping, no change in full scale

Load transducer creep

≤0.03%F.S.

Temperature effect on load transducer sensitivity

≤0.03%F.S./10℃

Deformation measurement range

0~10 mm

Deformation measurement accuracy



±0.5%

Grip displacement measurement accuracy

±0.5%

Grip speed adjustment range

0.01~80mm/min

Grip speed accuracy

±0.5%

Loading speed adjustment Range

0.01%~2.5%F.S./s

Loading speed controlling accuracy

±0.5%

Temperature measurement resolution

0.1 ℃

Temperature measurement accuracy

±0.3℃(-20℃~80℃),±0.5℃(-40℃~-20℃/80℃~110℃)

Valid tensile travel

100 mm

Test space

Max distance between left/right grip: 2450 mm

Specimen dimensions

Diameter for steel strand: 12.7 mm, 15.4 mm, length ≥ 3.2 m

Diameter for PC steel rod: φ4mm~φ16mm, length ≥ 3.2 m

Frame dimensions

(2500×540×1055)mm

Power supply

1kW/AC220V/50Hz

Weight

Approx. 1600 kg
