Protection Relay Test Set

Protection Relay Test Set

Product Details:

Get a Price/Quote
Send Inquiry
X

Product Description

Description:

A test set that gives students theoretical and practical experiencewith a variety of industrial relays. The equipment uses industrial protectionequipment and techniques, and a range of industrial relays, adapted foreducational use. The test set allows students to compare individual relaycharacteristics. It also allows connection of two relays for experiments suchas relay discrimination. The test set includes meters, current and voltagetransformers power supplies, a configurable transformer and load resistors. Italso has a useful desk space for students to work on. The configurabletransformer has a star connected primary, but the secondary has multipletappings. So, the user may connect it as delta or star with different voltageratios. Controls on the lower panel of the test set allow the user to adjustthe test voltage supply, current and load resistances. A transmission line onthe upper panel of the test set allows students to set up distance protectionand parallel feeder tests.



Detailed Specifications:

Nett dimensions andweight:

  1. 2660 mm long x 1890 mm high x 1020 mm front to back and 731kg



Approximate packeddimensions and weight:

  1. 5 m3 and 930 kg



Nett and packeddimensions of Relays:

  1. Refer to separate datasheets.
  2. Recommended floor area :
  3. >1000 mm at the back of the test set and >2000 mm aroundthe front and sides



Controls andinstrumentation:

  1. 0 to 220 V variable voltage supply
  2. 0 to 10 A variable current supply
  3. Two fault limiting resistors
  4. Timed fault application circuit breaker
  5. Configurable tapped transformer with delta or star secondary
  6. Variable three-phase load delta connected
  7. Variable three-phase load star connected
  8. Four sets of three-phase current transformers
  9. Two sets of three-phase voltage transformers
  10. Mains isolator
