Manual Combined Extraction And Distillation Plant

Product Description

Manual Combined Extraction and Distillation Pilot Plant Extraction column height 1,500 mm consisting of 26 stages. Including a disc stirrer, 2 glass separators and a variable speed motor 0 to 1,000 rpm2x metering pumps with a flow rate of 0 to 40 litres per hour.Distillation column with vacuum jacketReflux headSolenoid valve for controlling the reflux ratioReboiler with a capacity of 7 litres for the distillation columnElectric heater 3,000 watts for reboiler.Thyristor unit for controlling the power to the reboiler electric heater.2x programmable timers for controlling the reflux ratio.Flow meter for feeding the water to the overhead condenser with a range of 20 to 250 litres per hour.3x thermocouples with probes protected by stainless steel shield sleeves3x electronic digital temperature indicators.Tube-in -tube heat exchangers for cooling the liquid produced from the extraction column Tank with a capacity of 3 litres for collecting the liquid produced from the extraction column Graduated tank with a capacity of 1 litre for collecting the distillateElectrical control panel in main cabinetPipe work and valves manufactured from stainless steelEmergency stop button
