Electronic Tensile Stress Relaxation Testing Machine

Product Description

Electronic Tensile Stress Relaxation Testing Machine, Stress Relaxatin TesterFeatures of Electronic Tensile Stress Relaxation Testing Machine, Stress Relaxatin TesterThe measurement and control system is capable of backing up the transducers calibration data, improving the systems maintenance reliability.Dynamic display of load, displacement, deformation and real-time testing curve on the screen.Support saving, instant retrieving and inspection of testing results.Capable of re-analyzing test data and curves, and partial zooming of testing curves at will.Open testing report, support custom testing template, automatic generation of testing report, which can be printed, previewed or saved as files.Support Excel report templates and customized editing of test reports.Integrated with travel limit protection and full scale overload protection.Features a large test space that satisfies both GB requirements (longer than 60 times the specimens diameter), as well as American and European requirements (not less than 2.4 meters).Real-time drawing of curves of remaining load with time, or temperature with time.Algorithm to predict specimens stress relaxation performance after 1000 hours (or any specified value in hours), with the option of single or double logarithm. Capable of predicting with standard specimen data or real-time collected data (Suggested). Integrated with an extensive specimen library to improve the precision and reliability of testing results. Technical Specifications Capacity 400kN Load measurement range 8 - 400kN Load measurement accuracy 0.5% Load resolution 1/500000 of Max capacity, no stepping, no change in full scale Load transducer creep 0.03%F.S. Temperature effect on load transducer sensitivity 0.03%F.S./10 Deformation measurement range 0 - 10 mm Deformation measurement accuracy 0.5% Grip displacement measurement accuracy 0.5% Grip speed adjustment range 0.01 - 60mm/min Grip speed accuracy 0.5% Loading speed adjustment Range 0.01% - 2.5%F.S./s Loading speed controlling accuracy 0.5% Temperature measurement resolution 0.1 Temperature measurement accuracy 0.3(-20x80),0.5(-40x20x80x110) Valid tensile travel 100 mm Test space Max distance between left/right grip: 2450 mm Specimen dimensions Diameter for steel strand: 12.7 mm, 15.4 mm, length 3.2 m
