Domestic Heating Unit

Product Description

Domestic Heating UnitDomestic Heating Unit has been designed to enable the students to become familiar with the problems encountered in the construction and management of heating systems fuelled by a liquid and using water as their heat distribution medium. The power station is made up of a boiler with a gas-oil burner, and it uses a closed system and automatic water charging from the network. With Domestic Heating Unit it proves possible to study three different systems: Module Areas, Single-Pipe, and Floor Plant.The Domestic Heating Unit is provided with an electrical control board including all the instrumentation necessary to control and check the efficiency of the boiler and the distribution efficiency of the chosen system; a metering system for the heat used up by the distribution system can also be provided.Technical specifications of Domestic Heating UnitRecirculation water pump and water supply pump Power: 43W Max. flow-rate: 33 l/min Three rotation speeds Burner Single stage pressure drop type Fuel consumption 2 to 3.3 kg/h Power from 23.7 to 39.1 kW Boiler Thermal power: 23.6 kW Capacity: 14.5 l Maximum working pressure: 4 bar Elements: 3 Dimensions: 450 x 380 x 850 h mm Required services of Domestic Heating Unit Electrical power supply: 220/240 V single-phase - 50/60 Hz Water supply: 3 bar, 15 lt./h Weights and dimensions of Domestic Heating Unit Dimensions: 2450 x 1500 x 1750 h mm Net weight: 450 kg
