Combined Wind And Solar Generator Demonstrator

Product Description

Description of DIDAC Combined Wind And Solar Generator DemonstratorA small solar panel with nominal 10W output is connected to a battery charge control system. The charge controller is also connected to a small wind turbine. The charge controller can be connected to the supplied 12V deep cycle lead acid battery.Combined Wind And Solar Power Generation is supplied with a 500W solar simulator that allows the panel to be irradiated and generate power within the laboratory. This allows students to investigate the relative magnitude of incoming solar radiation, relative to power generated.Experimental Capabilities of Combined Wind And Solar Generator DemonstratorInvestigation of the components of a Combined Wind And Solar Power Generation systemInvestigation of the effect of panel output voltage with solar irradiation.Investigation of the effects of shading on a practical solar installation.Examination of battery charge management system.Investigation of a wind power generator.Investigation of the effect of wind direction on generator performance.Investigation of the change in air momentum before and after the generator: -When generating powerWhen not generating powerExamination of a battery charge management system.Attachment of Optional DC Loads
