Universal Tool Grinder

Universal Tool Grinder

Product Details:

X

Product Description

Description:

  • The worktable of uses the dovetail guide rail, good rigidity, And uses two high precision straight line roiling guide rails, steady bed platform, good movement. can grind in hole and outer annulus.

  • Standard accessories can grind slot miller, face and side cutter, lathe tool, hobbing cutter, reamer bit etc.

  • The motor can be rotated 360 on both sides of the grinding wheel, grinding cutters of different materials, as long as the rotation of the grinding wheel, increase security and reduce wheel swap and finishing time, increase tool grinding manipulative.

Technical Specification:

Model

DIGR053

DIGR053/1

About worktable diameter

300mm

350mm

About worktable traveling schedule

150mm

Worktable area

130x550mm

130x675mm

Grinding wheel size

125x50x32mm

150x16x32mm

Power/Speed

2800RPM

5000RPM

Motor

3/4HP 220V/380V

Dimension

70x63x63cm

73x71x72cm

Weight

168kg/160kg

209kg/222kg
