Three Hinged Arch

Three Hinged Arch

Product Details:

X

Product Description

Specification of Three Hinged Arch
  • Investigation of two statically determinate three-hinged arches.
  • Three arch segments: 2x long (together making a symmetrical arch), 1x short (together with 1x long: unsymmetrical arch)
  • Hinged arch with three hinges: one crown hinge, two abutment hinges at the bearing points.
  • Arch subjected to point load, distributed load each by weights or moving load.
  • Four sets of weights to compensate for the support reactions of an abutment hinge.
  • Storage system to house the components.
  • Experimental set-up in frame.
