Synchronous Machine 60 HZ

The Synchronous Machine runs at constant speed independently of the load. The synchronous speed directly depends on the current frequency and on the number of motor poles. The main characteristic of a Synchronous Machine is the possibility to change the power factor. Its stator is connected to an AC power supply and its rotor must be linked to a AC/DC rectifying unit. The Synchronous Machine is designed to operate as a motor or as an alternator. The rotor works as a square cage when starting and stopping. The three-stator windings are brought out to 4-mm separated terminals on the housing, so that they may be connected in wye or delta. The trainer is also provided with supply terminals, a rheostat for control over the excitation current and a protective circuit breaker in the rotor circuit. Specifications and/or diagrams are silk-screened on the back of a clear-plastic front panel for ease of identification. The trainer is protected by a either a diode or thermal-magnetic circuit breaker. Included in the Rotating Machines Trainer for 1/3 hp - 250 W. Requires a 120V 60Hz circuit.

Educational Advantages of Synchronous Machine



  • Designed to operate as a motor or as an alternator
  • Its stator must be connected to the AC power supply
  • Its rotor must be linked to the  AC/DC rectifying unit and works as a square cage when starting and stopping
  • Included in the basic Rotating Machines Trainer (50016) for 1/3 hp - 250 W



Technical Specifications of Synchronous Machine

As Motor



  • Power: 120/208 VAC, 3Φ
  • Speed: 1800 rpm
  • Number of stator windings: 3 (wye/delta)
  • Rotor field rheostat: 200 Ω, 50 W



As Alternator



  • Power: 120/208 VAC, 3Φ
  • Output: 120 VA
  • Speed: 1800 rpm
  • Power factor: 0.8
  • Thermal breaker protection
