Switchable Capacitor Battery

Product Description

Switchable Capacitor Battery

Switchable Capacitor Battery system with which different capacitance values can be connected to the mains for reactive power compensation. Four switching levels each consisting of 3 capacitors in star connection with discharging

resistors:

• level 1 (b1 coil): 3 x 2 ¼F/450 V
• level 2 (b2 coil): 3 x 4 ¼F/450 V
• level 3 (b3 coil): 3 x 8 ¼F/450 V
• level 4 (b4 coil): 3 x 16 ¼F/450 V

Compensation power: max 1360 VAr at 50 Hz, 380 V

Each switching level can be controlled separately: internally, through 4 toggle switches, externally, through 4 control inputs Coil operating voltage: 220 Vac
