Simple Mechanisms kit

Simple Mechanisms kit

Product Details:

X

Product Description

Description:

The Simple Mechanisms experiment kitenables students to visualise and understand the different types of mechanicalsystems and the conversion of linear motion to rotary motion and vice versa.



Features:

  1. Appliedstudent learning via Building and experimentation
  2. Supplied witha detailed instruction manual, covering the theory of Simple Mechanismsincluding multiple practical experiments designed to further develop thestudents understanding in this field.
  3. Hands-onLearning Clear and concise pictorial assembly instructions enhance the learningexperience
  4. Multipleexperimental capabilities per self-contained kit
  5. Tool-Lessassembly



Specification:

  1. Acrylic /Perspex fluorescent lava orange protractor wheel
  2. Whitworthdrive stub
  3. Acrylic /Perspex crank & slider links
  4. White Perspexslotted links
  5. White PerspexWhitworth links
  6. White Perspexscotch yoke & indicator
  7. Mechanismslink - indicator
  8. Stub handle
  9. Oscillatingcylinder washer
  10. Perspexindicator slide block
  11. Slotted linkpivot spacer
  12. 5mm Perspexslide block spacer (100mm x 62.5mm)
  13. 12mm Perspexslide block spacer (100mm x 62.5mm)
  14. 2 x four barlink plates
  15. Four barpivot nuts
  16. M6 x 12 thumbscrew din 653, grade 4.8 zinc plated
  17. Knurled thumbnut m6, brass thread, nylon body
  18. Knurled thumbscrew m6 x 40mm, nylon body
  19. Knurled thumbscrew m6 x 20mm, nylon body
  20. Knurled thumbscrew m6 x 10mm, nylon body
  21. Thick nylonM12, 27mm OD washer
  22. Perspexmagnetic indicator
