Photoelastic Experiments with a Transmission Polariscope

Specification of Photoelastic Experiments With A Transmission Polariscope

  • Representation of mechanical distribution of stress in photoelastic experiments
  • 2 plane polarisation filters as polariser and analyser
  • 2 quarter wave filters to generate circular polarised light
  • All filters with 360° angle scale and marking of the main optical axis
  • White light generated using a fluorescent tube and two incandescent lamps
  • Monochromatic light (colour yellow) generated using a sodium vapour lamp
  • Filters roller bearing mounted and rotating
  • Frame cross-arms height-adjustable
  • Generation of compression or tension forces by means of a threaded spindle
  • Complete models in polycarbonate (PC) for demonstration purposes available as accessories

Technical Data

  • Light source
  • Lamp box with white diffuser
  • For white light
  • 1 fluorescent tube tl-e 32w/33 (colour: 33)
  • 2 incandescent lamps, candle bulb, matt inner e14,
  • 235v, 25w
  • For monochromatic light (colour yellow)
  • 1 sodium vapour lamp sox 35, 35w
  • Filter, enclosed in glass, diameter: d=425mm
  • 2 polarisation filters (dark olive)
  • 2 quarter wave filters (colourless)
  • Frame WxH: 600x750mm
