Loading and Buckling of Struts

Description of Loading and Buckling of Struts

The Loading and Buckling of Struts allows tests on a full range of struts. It shows load and deflection characteristics and buckling loads for various strut lengths, Cross-section and end conditions. It also allows studies of the effect of eccentric loading. An optional set of extra specimens allows extra tests to show students some of the more complicated problems found in strut design. The main part of the apparatus is a precision-engineered rigid aluminium base, with legs and levelling feet. At one end is a loading device which uses a screw to apply loads to the struts. The screw is in fixing blocks with bearings to give precise and easy load application. Holders are at both the loading and load measuring ends. They allow students to create any combination of ‘pinned’ or clamped end conditions for the strut under test. Supplied is a set of special end fittings for tests with various eccentricities to show the effect of eccentric loading. The equipment includes a lateral pull attachment for Students to apply light biasing loads, or larger side loads, as needed. Students can also set up the apparatus to examine flexural rigidity and general beam deflection theory.

The two special struts show how buckling loads may be lower than the ideal values, because of two reasons:



  •         Flexure of the end fixings
  •         Imperfect shearing connections between the parts of a compound strut



Experiments of Loading and Buckling of Strut



  •       Demonstration of buckled (crippled) shape of struts with different end conditions.
  •       Determination of load/deflection curves and buckling loads for struts of different lengths and cross-sections, with any combination of ‘pinned’ or clamped end fixings.
  •       Comparing experiment results with those using Euler’s buckling theory
  •       Investigation of the effects of side load and eccentric loading on strut buckling characteristics.
  •       Flexural rigidity and buckling loads for struts of different materials.
  •       The use of South well’s method to estimate buckling loads and strut eccentricities from experimental results.
  •       Determination of flexural rigidity and comparison with calculated values.
  •      Deflections of a simply supported beam with a point load including the verification of general deflection formulae, and the deflected shape.



Standard Features of Loading and Buckling of Struts



  • Supplied with comprehensive user guide
  • Five-year warranty
  • Manufactured in accordance with the latest European Union directives



Specification of Loading and Buckling of Struts



  •         Nett dimensions and weight of main part: 1350 mm long x 500 mm wide x 500 mm high and 24 kg
  •         Nett dimensions and weight of digital load meter: 170 x 60 x 200 mm, 1.4 kg
  •         Nett weight of additional beams and other items: 1 kg
  •         Packed dimensions and weight of complete package: Approximately 0.5 m3, 40 kg
