Hydraulic Servo System

Hydraulic Servo System

50000.00 - 500000.00 INR/Pack

Product Details:

X

Hydraulic Servo System Price And Quantity

  • 50000.00 - 500000.00 INR/Pack
  • 1 Pack

Hydraulic Servo System Trade Information

  • 10 Pack Per Month
  • 10-30 Days
  • Export Worthy
  • ISO

Product Description

Hydraulic Servo System

Technical Description of Hydraulic Servo System

Servo systems are closed-loop control systems. In many industrial applications it is often required to convert small mechanical motions into a different motions with increased force. Hydraulic systems are particularly suitable for applications where large actuation forces are required. The unit allows the operation of a hydraulic servo system to be investigated in detail. A carriage with a mass of 50kg is moved by a hydraulic cylinder. Additional springs and an adjustable hydraulic damper permit static and dynamic loads to be simulated. The displacement of the carriage is established using a potentiometric position sensor and compared against the reference variable. The control deviation is processed in a separate servo amplifier. Depending on the direction of the deviation, a control valve is activated in forward or reverse direction, which in turn produces a corresponding movement of the hydraulic cylinder and the carriage. The trainer is a mobile unit. Measuring devices can be housed in the built-under cabinet unit.

Specification of Hydraulic Servo System

  • Self-contained training system of a complete hydraulic position control loop with adjustable loading conditions
  • Oil circuit with hydraulic unit, hydraulic accumulator, 2 manometers, control valve and hydraulic cylinder to move a weighted carriage
  • Operation of the electromagnetic control valve for position control by proportional amplifier
  • Proportional amplifier with adjustable gain and recorder
  • All control variables available as voltage signals 0...10V









Technical Data of Hydraulic Servo System

Hydraulic unit

  • Power output: 1,1kW
  • Flow rate: 3,8L/min
  • Head: 1500m
  • Tank capacity: 10L
  • Hydraulic accumulator capacity: 2L
  • Accumulator charging valve: max. 40L/min











Hydraulic cylinder

  • Piston diameter: d=40mm
  • Stroke: 150mm
  • Mass moved: 50kg





Control valve NG6

  • Nominal flow rate: 24L/min
  • Activation: +/-10V



Potentiometric position sensor

  • Measuring range: 150mm
  • Output: 0 ¦10V



Dimensions and Weight of Hydraulic Servo System

  • LxWxH: 1600x700x1700mm
  • Weight: approx. 414kg
