Hydraulic Fatigue Testing Machine with Dynamic Display for Fatigue Test

Description of Hydraulic Fatigue Testing Machine with Dynamic Display for Fatigue Test

This product is integrated with a high-stiffness frame. The crossbeam is hydraulically driven to adjust the test space. The precise actuator collaborates with the intelligent Test Live computer testing software to ensure the completeness and precision of the test results. The rated load of the main frame ranges from 5 to 25kN or 50 to 1000kN. The actuator cylinder comes out in 100mm, 150mm, 400mm and many other models.

Technical Specifications





Model

DIFT005/1


DIFT005/2

DIFT005/3

Capacity (kN)

200


500

1000

accuracy class

1


1

1

Load measurement range (%)

1-100


1-100

1-100

Actuator dynamic stroke (mm)

150,250


150

150

frequency range (Hz)

0.01-50


0.01-50

0.01-50

Number of Column

2


2

4

test space rang (mm)

700


800

800

test space width (mm)

550


650

650

Base width (mm)

1100


1300

1300

Base depth (mm)

800


900

1300

Overall height (mm)

2350


2500

2500

Weight (kg)

1500


2500

6000
