Hot Water Generator

Product Description

Hot Water Generator

Specification of Hot Water Generator

1. Hot water generation for room heating
2. Boiler with oil burner, boiler safety group, low water-level switch and circulating pump in feed flow
3. Oil tank with pump and safety fittings
4. 3 dial-gauge thermometers
5. 2 temperature sensors and 1 differential pressure manometer for measurement of temperature and pressure at different measuring points
6. Hot water connections with quick-release couplings

Technical Data

Boiler

1. Heating capacity: 17...21kw
2. Max. Water temperature: 75°c
3. Water content: 50l
4. Max. operating pressure: 3bar

Boiler Safety Group According

1. 2,5bar
2. 50kW

Expansion vessel

1. Capacity: 12L
2. Max. pressure: 3bar
3. Circulating pump, feed flow
4. Max. Power consumption: 60w
5. Max. Flow rate: 3600l/h
6. Max. head: 4m
7. Oil tank: 36L

Measuring ranges

1. Temperature: 1x 0...300°c, 4x 0...100°c
2. Differential pressure: 0...2,5bar
