Geothermal Energy Absorber Unit

Geothermal Energy Absorber Unit

Product Details:

X

Product Description

Under floor Heating / Geothermal Energy Absorber

Specification



  1. Heat sink or heat source for the modular system
  2. Three selectable pipe lengths for heat transfer
  3. Flow meters and temperature sensors for determining the heat flows
  4. Tanks for hot or cold water
  5. Connections for transmitting measurement data to an external controller



Technical Data

 Pipes



  1. Lengths: 10m, 20m, 30m
  2. Material: polyethylene
  3. Wall thickness: 2mm
  4. Outer diameter: 16mm
  5. Operating pressure: max. 3bar



Tank



  1. Volume: 200L



Measuring ranges



  1. Temperature: 0...160°c
  2. Flow rate: 0...1000L/h
