Feeder Manager Relay

Feeder Manager Relay

1200000 INR

Product Details:


Price And Quantity

  • 1200000 INR
  • 1 Piece

Trade Information

  • Export Worthy
  • ISO

Product Description

Feeder Manager Relay


Three-phase Current, Voltage and Earth Fault multifunction relay for protection and management of MV/HV distribution lines. Real time measurement of the primary value of the input quantities are continuously available from relay's display and from the serial communication port. Relay's programming and setting can be made directly by the front face keyboard or via the serial communication ports. Setting, event recording and oscillography are stored into nonvolatile memory. The relay is fitted with a multivoltage, auto ranging power supply unit self protected and transformer isolated.

  • Three levels for phase current independently programmable as directional or non directional
  • Three levels for Earth Fault independently programmable as directional or non directional
  • Selectable Time current curves according to IEC and IEEE standards
  • Two over/under voltage levels
  • Two over/under frequency levels
  • Zero sequence over voltage level
  • Two Negative Sequence current levels
  • One Positive Sequence over voltage level
  • One Negative Sequence under voltage level
  • Two Reactive Power (VAR) control levels (optional)
  • Trip circuit supervision
  • Associated Circuit Breaker control (OPEN /CLOSE)
  • Breaker failure protection
  • Output relays totally user programmable
  • Digital inputs user programmable
