Fault Finding In Control Systems

Specification: Fault Finding In Control Systems

  • Control of level, flow rate, temperature and cascade control
  • Main circuit with collecting tank, graduated stirred tank with heater, pneumatic control valve and centrifugal pump
  • Cooling circuit with pump, heat exchanger and rotameter
  • Refrigeration system and pump to cool the water in the collecting tank
  • Pneumatic control valve in main circuit as actuator for all controls
  • Sensors for the measurement of the controlled variables; level, flow rate and temperature
  • 2 parameterisable industrial controllers
  • 6 pushbuttons for fault simulation
  • PLC to monitor safety devices

Technical Data

Tanks

  • Stirred tank with scale: approx. 7L
  • Collecting tank: approx. 90L

Main circuit centrifugal pump

  • Max. flow rate: approx. 75L/min
  • Max. head: approx. 20m

2 pumps, cooling circuit and refrigeration system

  • Max. flow rate: approx. 60L/min
  • Max. head: approx. 4m
  • Heater power output: approx. 2kW
  • Controller parameterisable as
  • P, PI or PID controller
