Door Module Proline

Door Module Proline

Product Details:

X

Product Description

Features

  1. Original parts, power windows, door controlunit, central locking, child lock, emergency lock, door lock
  2. Mirrors electrically adjustable, heated,mirror turn signal
  3. Breakout box for door control unit with allused pins of the controller, 38 x jumpers equipped with measuring tap
  4. Fault circuit with 12 x system errors
  5. The window regulator mechanism and internalcomponents are visible and protected by a polycarbonate cover
  6. Compact device build, mobile, for lab andworkshop practice



LearningObjectives

  1. Working with original schematics and specifyproblem-oriented connector pins on components and control unit
  2. Making screen-shots of all signals, allcontrol voltages and the CAN data-bus with a digital oscilloscope and storingthem for customer-specific documentations
  3. Recording CAN-bus signals with theoscilloscope and assessing signal levels
  4. Actuator diagnosis e.g. via VCDS
  5. Control of components through e.g. PCAN-DongleUSB, controlling using its own switches
  6. Visualization of the CAN data transmissionwith e.g. PCAN-Dongle
  7. Practical errors: detect and evaluate cablebreaks and corrosion resistances
  8. Self-diagnosis with OBD diagnostic tool fromLighting Board Central Electrics



TechnicalSpecifications

  1. Connection: Connecting cable with plug
  2. Dimensions: W x H x D: 142 x 71 x 193 cm
  3. Weight: about 55 kg
