Digital Display Electronic Universal Testing Machine

Digital Display Electronic Universal Testing Machine

Product Details:

X

Product Description

Digital Display Electronic Universal Testing Machine

Main features of Digital Display Electronic Universal Testing Machine

  • This machine equips alternating servomotor for driving crosshead and imported photoelectric encoder for displacement measure. This machine is accompanied with the digital multi-channel closed loop control system, which apply with the latest measurement and control systems with lots of advanced professional and technical development.
  • The test adopt high accuracy and digital speed system, precision decelerate structure and precision drive screw ball to realize the max range of test speed. During the testing there is lower noise and smooth operation.
  • Touch button operation, LCD display screen. It includes test methods display screen, test force display screen, test operation and result display screen and curve display screen. It’s so convenient and fast.
  • It can achieve the adjustment of crosshead’s speed when clamp the specimen.
  • Adopt the USB connector . it can connect the computer to achieve the data’s memory, analyze, print and display.

Technical Specifications:


Max. test force

50 KN

Measurement range of test force

2%-100%

Test force accuracy

±1%

Displacement measurement resolution

0.01mm

Speed of displacement

0.01-500mm/min

Deformation accuracy

≤±1%

Tensile test space

550mm

Compression test space

600mm

Host type

door structure

Host dimension

600mm x 450mm x 1500mm
