Compression Machines 2000 KN To Test Cylinders And Cubes High Stability Motorized

Description of Compression Machines 2000 KN To Test Cylinders And Cubes High Stability

Compression testing machines 2000 KN Capacity tested for high stability to test cubes up to 200 mm side and cylinders up to dia. 160x320 mm.

Technical Specifications:



  • Max. vertical daylight: 336 mm
  • Compression platens dia. 287x60 mm
  • Gauges dia. 250 mm with specific resistance scales for cubes 150 mm and cylinders dia. 150 and 160 mm
  • Gauges divisions: 2000 KN div. 5 KN - 600 KN div. 2 KN
  • Calibration accuracy: Grade 1.0
  • Max. Ram travel 60 mm approx.
  • Hydraulic device to stop the pistons stroke at its max excursion, to avoid pumping the piston out of the cylinder.
  • Power supply: 230 V 1 ph 50 Hz 750 W
  • Dimensions: 690x400x1400 mm
  • Weight: 850÷920 kg



Standards



  • DIN 51302
  • UNI 6686 PART 3
  • BS 1881:115
  • EN 12390-4
  • DIN 51220
  • UNE 83304
  • NF P18-411
  • AASHTO T22
  • ASTM C39
