Central Heating System

Central Heating System

Product Details:

X

Product Description

Hot Water Generator

Specification Of Hot Water Generator



  1. Function and operating behaviour of a modern heating system with digital heating controller
  2. 4-way mixing valve and 3-way mixing valve
  3. Electric boiler
  4. 2 circulating pumps, 1 domestic water pump
  5. 4 different radiators and additional plate heat exchanger as domestic water consumer
  6. Coloured pipes indicate feed and return flow
  7. Measurement of temperature, pressure and flow rate



Technical Data

Electric Boiler, 4 stages



  1. Power: 6-9-12-15kw
  2. Max. Feed temperature: 95°c
  3. Water tank capacity: 16l



Pump



  1. Power consumption: 70W
  2. Max. Flow rate: 6L/min
  3. Max. head: 4m



Domestic Water Pump



  1. Power consumption: 20W
  2. Max. Flow rate: 640L/h
  3. Max. Delivery pressure: 0.14bar
  4. Plate heat exchanger: 3kw, 10 plates
  5. Water meter: 2.5m³/h



Measuring Ranges



  1. Temperature: 3x 20...120°c / 2x 0...120°c /
  2. 2x 0...100°c / 4x 0...80°c
  3. Pressure: 8x 0...2.5bar
  4. Flow rate: 100...1.000l/h
