Capstan Lathe

Capstan Lathe

Product Details:

X

Product Description

Description:

The Capsten lathe belongs to the light duty kind of lathes and it is featured with turret head on the ram. The ram is them fixed on the saddle which will not move at the time of tooling. It suits perfect for performing machining over short work materials. The turret head is flexible for making sliding movement over the ram. It stays suitable equipment for industries which require identical kind of tooling frequently. This equipment can also be applied to obtain different cuts by rotating the turret head on the black wherein it becomes quite flexible and fast to work with. Above all, when it is comes to user friendly features in cutting, Capsten apparatus from DIDAC Machine Tools is one of the best options.

Technical Specification:

Models

DIGR064

DIGR064/1

DIGR064/2

DIGR064/3

DIGR064/4

DIGR064/5

Spindle hollow (mm)

25

28

32

38

42

42

Maximum collect capacity (mm)

20

25

25

32

40

40

Range of spindle speeds (RPM)

650-1660

650-1660

275-900

165-1500

165-1500

100-1050

Effective strokes of turret slide(mm)

100

110

130

140

140

165

Bore size in turret hex head

25

25

25

25

32

32

Center of holes above turret slide (mm)

45

45

45

45

45

45

Max. dist. Between

300

375

400

425

425

430

Spindle Nose To Turret Face (mm)

Cross slide traverse travel (mm)

95

95

95

95

95

150

Cross slide longitudinal travel (mm)

300

300

300

300

300

300

Length of bed (mm)

980

1050

1275

1225

1225

1375

Width of bed (mm)

178

178

178

178

178

230

Height, of center above bed (mm)

165

165

165

165

165

190

Floor space required (mt.)

2.5x1

2.5x1

3x1

3x1

3x1

3x1

Packing size (approx)(Sq.ft.)

4x3x5

4x3x5

4.5x3x5

5x3x5

5x3x5

5x3x5
