Description of Boiler control Demonstration and Fault Simulation Unit:

An arrangement of up to date integrated circuits is used to simulate boiler pressure and burner control together with the sensing and control systems associated with modern boiler systems. The simulated boiler itself is constructed from a clear acrylic tank and thus the demonstration unit provides a clear visual appreciation of the operating characteristics of the various level controls i.e. float operated magnetic, reed or electronic system using electrode sensors. The operation of these level sensing devices can readily be investigated since they may be removed from the Demonstration Unit, dismantled and re-assembled, without the attendant problems which would occur on an operational boiler. These systems would not normally all be fitted in the same boiler but are included in this unit to give the student an appreciation of the characteristics of each system. Conversion of water from the boiler into steam is simulated so that the level sensors need to operate as in a true Boiler system. A Boiler Water Gauge is fitted to the Boiler Drum so that possible misuse of this item can be demonstrated clearly and safely. This Gauge can also be used to demonstrate the method of changing a ‘sight glass’ for such a gauge under simulated working conditions, a circumstance which can be ‘safely’ taught on this Demonstration Unit.

Experimental Capability of Boiler control Demonstration and Fault Simulation Unit:



  1. Designed to provide demonstration and investigation of:
  2. Automatic operational functioning of an oil/gas fired boiler  Predetermined faults imposed on the system
  3. Safety control operation
  4. Feedwater pump control by various methods
  5. Basic boiler mounted indicating and control systems
