Automotive Oscilloscope Trainer

Automotive Oscilloscope Trainer

Product Details:


Product Description


  1. Sine,square, and pulse width modulated control of components
  2. Automotiverelating with two classic components: heating element and electric motor
  3. Sixindividual errors can be selected by rotary switch for both components
  4. Fortroubleshooting and measurement 35 test sockets are available
  5. Coloredprinted circuits in standard-compliant display



  1. Withthe help of sine and square wave signals you learn the fundamentals foreffective value (RMS) and learn how to use your gauge
  2. Usingthe oscilloscope to measure voltage
  3. Measuringin the correct place in the harness
  4. Ratemeasured signals correctly and thus identify the main cause of an error
  5. Insertpart voltage measurements in intact and defective circuits as a diagnosticmethod



  1. Powersupply: 110/220 Volt AC
  2. Dimensions:L x W x H 297 x 266 x 80 mm
  3. Weight:about 3 kg
