Absorption Refrigeration Cycle Study Unit

Product Description

Absorption Refrigeration Cycle Study Unit

The Absorption Refrigeration Cycle Study Unit is an extremely easy-to use and functional unit able to permit the study of an absorption refrigerating cycle. Afront panel with mimic diagram and instrumentation allows to keep the most significant thermodynamic quantities undercontrol, so facilitating the studentsâ„¢ understanding and the teachers task. The main characteristic of the Absorption Refrigeration Cycle Study Unit is to enable the student to observe the absorption refrigerating cycle. The cycle peculiarityis to generate low temperature using an heat source. The heat can be produced or by an electric source or by a gas burner.The cooling fluid is ammonia (NH3), housed in a sealed circuit. The unit is supplied with the electric resistance heater, but it is possible, on demand, to have the gas burner. A refrigerating room allow the cooling effect visualization.

Technical features of Absorption Refrigeration Cycle Study Unit

• Absorption group power 130 W

Required services of Absorption Refrigeration Cycle Study Unit

• Electrical supply 220V single-phase, 50Hz

Weight and dimensions of Absorption Refrigeration Cycle Study Unit

• Dimensions: 600X600X1530 h mm
• Net weight: 86 kg
